| Sensing Volume: | ~ 190 cubic meters of useful space, over 7.0 meters radius (at min. exposure) |
| Minimum Sensing Distance: | 0.5 meter |
| Distributive Tactile Feedback: | Yes |
| Position Resolution: | 0.015 mm at 1.2m distance |
| Number of Markers: | 512 max (no 'swapping' problem) |
| Number of Subjects: | 512 maximum |
| Calibration: | Not required for an individual tracker Not required for multi-tracker systems either, if VZAutoCal is used |
| Scalability: | 1~24 trackers (verified), (unlimited in theory) |
Accuracy (3D combined, nominal): (see definition) | <0.5mm RMS (H-series) 0.5~0.7mm RMS (E-series) (Calibration data range: 0.6~2.2m distance, ±30° yaw, ±30° pitch) |
| Operation Angle: | 90° (±45°) in both pitch and yaw (107° diagonally) |
| Sensing Rate: | 4850 real-time 3D data points per second (single sampling, 'vbr' series) 4167 real-time 3D data points per second (double sampling) |
| Data Latency: | < 0.0005s at maximum sample rate |
| Computer Communication: | Serial RS232/RS422 (921.6kbps) real-time protocol |
| Mounting Orientation: | Any (no 'blinding' problem) |
| Ruggedness: | Can operate with up to 15G acceleration applied to the tracker (optional) |
| Tracker Bar Weight: | 3 Kg |
